CLASSEQ P500 Pass Through Dishwasher 3 Phase 22 AMP
High volume digital dishwashers suitable for straight-through or corner situated operation, the P500A machines are capable of washing up to 720 plates per hour.
Reduced water consumption via 28 litre wash tank ensures minimised running costs. Easy cleaning due to the continuous hood clean and removable front panel allows excellent service access.
The P500A comes with a WRAS compliant type AB air gap, drain pump and rinse booster pump as standard. A detergent and rinse aid pump can be added as an optional extra.
Standard P500A machines can be specified in either single phase 30Amp operation or 3 phase 12Amp, 16Amp or 22Amp.
Dimensions:
Width: 635 mm
Height: 1460 mm
Depth: 712 mm
Height – Hood Open: 1955-2010mm
Height – Hood Closed: 1460-1515mm
Maximum clear entry height: 440 mm
Water inlet height floor level: 255-310mm
Drain height floor level: 0-700mm
Drain Size: o40mm
Basket Size: 500 x 500 mm
Performance:
Theoretical max racks per hour: 40
Plates per rack : 18
Number of wash programmes: 3
Duration of wash programmes: 1.5, 3 & 5 minutes
Noise level: < 70 dB
Net weight: 130kg
Wash pump size: 0.58kW
Wash pump capacity: 380 Ltrs/min
Wash tank heating: 4.05kW
Wash tank capacity: 28L
Wash tank temperature: 55 °C
Rinse boiler capacity: 7.5L (Everyday & Intermediate Use) / 12L (Intensive Use)
Rinse boiler temperature: 82°C
Rinse water consumption at 2 bar: 3 Ltrs
Hydraulic Specifications
Water supply connection: G3/4″ (3/4″Bsp)
Required water pressure : 2-4 bar
Required water flow rate: 11L/min
Required Water Flow Rate with integral water softener: 4 L/min
Electrical Specifications:
Operating voltage – Standard: 380-415AC/50/3N
Operating voltage – Optional : 220-240AC/50/1N
Amps required – 3 Phase: 40°C
Water fed @ : 10°C
Rinse Boiler Heating
Everyday Use – P500A-12 (380-415AC/50/3N): 6 kW
Everyday Use – P500A-30 (220-240AC/50/1N): 6 kW
Intermediate Use – P500A-16 (380-415AC/50/3N): 8.64 kW
Intensive Use – P500A-22 (380-415AC/50/3N): 12 kW
Total Connected Load
Everyday Use – P500A-12 (380-415AC/50/3N): 6.68 kW
Everyday Use – P500A-30 (220-240AC/50/1N): 6.68 kW
Intermediate Use – P500A-16 (380-415AC/50/3N): 9.32 kW
Intensive Use – P500A-22 380-415AC/50/3N: 12.68 kW
